MEAN WELL TS-400-224B – 400W True Sine Wave DC-AC Power Inverter

*Please read full description prior to purchase*

**eBay policy restricts the display of phone numbers in the listing**

visit our page Gearheadsurpluscom!!

SELLING "AS IS - WHERE IS" AS DESCRIBED

** see all pictures**

MEAN WELL TS-400-224B – 400W True Sine Wave DC-AC Power Inverter (24V DC Input → 230V AC Output)

High-quality pure sine wave inverter from MEAN WELL’s trusted TS-400 series. Converts 24V DC (21–30V range) battery power into clean 230V AC electricity suitable for sensitive electronics and motor loads.

Key Specifications

• Continuous power: 400W
• Peak / surge power: Up to 800W (30 cycles); 600W for 10 sec; 460W for 180 sec
• Input: 21–30 VDC (nominal 24V), ~20A typical
• Output: 230V AC (selectable 200/220/230/240V), 50/60 Hz selectable
• Waveform: True sine wave, THD < 3%
• Efficiency: ~87.5% typical
• Dimensions: 205 × 158 × 67 mm
• Weight: Approx. 1.7–1.73 kg
• Operating temp: –10°C to +40°C at full load (up to +60°C at 50% load)
• Protections: Battery low alarm & shutdown, reverse polarity, over-voltage, overload, short-circuit, over-temperature
• Other features: Thermostatically controlled cooling fan, front-panel status indicators, power ON/OFF switch, remote ON/OFF capability, advanced microprocessor control

Ideal Applications

Home appliances, power tools, office/portable equipment, vehicles, RVs, boats/yachts, off-grid or backup power where clean AC is required.

• Genuine MEAN WELL quality – Reliable industrial-grade brand known for durability and consistent performance.
• True pure sine wave – Safe for sensitive electronics (laptops, TVs, medical devices, audio gear, variable-speed motors) unlike cheaper modified sine wave units.
• Strong surge capability – Handles motor start-up loads (tools, pumps, compressors) with up to 2× rated power.
• High efficiency (~87.5%) – Less heat, longer battery runtime.
• Comprehensive protections – Built-in safeguards protect both the inverter and your battery/equipment.
• Adjustable voltage & frequency – Flexible for different regional or equipment needs.
• Compact & well-built – Solid chassis-mount design with status indicators and remote control option.
• 3-year manufacturer warranty (original MEAN WELL coverage).
• Widely used for vehicles, marine, solar/off-grid, and portable power setups.

Note: This model has been marked obsolete by some distributors; availability is limited. Ideal for buyers seeking a proven, high-quality pure sine wave unit.

Perfect drop-in solution for clean, reliable AC power from a 24V battery system.
